02/02/2026
ABB’s new ACH580 UL (NEMA) Type 12 and Type 4X Vertical Bypass Drives are engineered for HVACR applications that demand reliability, protection and space efficiency. Designed for use in mechanical rooms, utility spaces and other demanding environments, this product combines ABB’s proven ACH580 variable frequency drive with trusted E-Clipse Bypass technology in a standardized vertical enclosure. The result is a compact and resilient package ensuring continuous operation of critical HVACR systems while protecting against dirt, debris and dripping water.
ACH580 drives deliver precise motor control, energy efficiency and intuitive operation for a wide range of HVACR equipment, including fans, pumps and refrigerant compressors. The integrated E Clipse Bypass ensures uninterrupted system performance by automatically transferring operation during maintenance activities or in the event of a drive fault. This combined technology increases uptime and provides peace of mind for facility managers and building operators who rely on consistent airflow and system resilience.
The innovative vertical design eliminates the need for bulky custom-built cabinets, as the drive and bypass are stacked in a narrow, wall-mounted configuration. This saves valuable wall space in crowded mechanical rooms, simplifies installation and enables a uniform approach across multiple sites and projects. Previously available in Type 1 configurations only, the Type 12 model adds environmental protection for indoor installations exposed to dust and moisture. ABB is also releasing a Type 4X model, extending these benefits outdoors by protecting against rain, ice and corrosion, perfect for coastal applications subject to salty sea spray and extreme conditions.
“Type 12 and Type 4X vertical offerings ensure users don't have to compromise between valuable space savings and higher degrees of protection that reduce maintenance needs and extend product longevity,” said Paul Olis, Product Market Manager, HVACR, ABB.
By expanding the Vertical Bypass family to include both Type 12 and 4X enclosures, ABB is delivering a standardized, space-saving solution that adapts to any environment. Together, the ACH580 UL Type 1, 12 and 4X Vertical Bypass offerings represent the next evolution in sustainable HVACR control.
About ABB Motion
ABB Motion, a global leader in motors and drives, is at the core of accelerating a more productive and sustainable future. With its digitally enabled drives, motors and services, the company supports customers and partners to achieve better performance, safety and reliability. Building on over 140 years of domain expertise in electric powertrains, its more than 23,000 employees across 100 countries learn and improve every day. For more information, visit https://www.abb.com/global/en/areas/motion.
